14Head Automatic Weighing Packaging Machine-Discrete Products Packaging System
Home » Turkey Solution » Multihead Weigher » 14Head Automatic Weighing Packaging Machine-Discrete Products Packaging System
Share to:

14Head Automatic Weighing Packaging Machine-Discrete Products Packaging System

* Applicable Bag Type: pillow bag, gusset bag, seal type bag.
* Applicable Film Materials: a variety of laminated films, single-layer PE film (Film Thickness Range: 0.04~0.15mm).
* Applicable Packing Material: a variety of rice, melon seed, corn, soybean, peanut, nut etc.

Quantity:
  • W14P420
  • Baixida
  • W14P420

Discrete Products Packaging System-14Head Automatic Weighing Packaging Machine

* Applicable Bag Type: pillow bag, gusset bag, seal type bag.

* Applicable Film Materials: a variety of laminated films, single-layer PE film (Film Thickness Range: 0.04~0.15mm).

* Applicable Packing Material: a variety of rice, melon seed, corn, soybean, peanut, nut etc.


Video

Discrete Products Packaging System Featuers:

 Color displayed Touch Panel + Stable Reliable PLC with Dual axis output high accuracy, thus the Bagging machine can final all steps in one-time, including bag Forming, filling, sealing, printing and cutting.
 Air and electric control are separated, less noisy and more stable.
 Panasonic Servo to drive pulley, two belts working at the same time, offering enough friction to pull film, less sliding, nicer bag and the belts will be longer life.
 External Film Holder assemblies with Screw inside, the film roll is fixed in center mandatory, no need extra adjustment, saving time.
 Adopts Motor to track the film. Operator can tune and center the film in Touch Panel directly. Automatic Tracking system is available to choose too.
 Most of electrical parts and pneumatic parts are protected, avoid dusty to damage the parts.
 Whole machine is made of SUS#304, including thick enough Stainless-steel tube and film bracket. Not SUS#201 or covered Iron. Thus the machine is stronger, longer life and more rustproof.
SPECIFICATIONS OF SMALL FOOD PACKING MACHINERY
Weight Machine
14heads weigher, 0.8Liter weight buckets
Weight Range
25-1000grams
Accuracy
±0.5~2g
Speed
5-100 bags/min (Depends on bag size, film feature and spec)
Languages
Default English or Chinese. For else Multiple languages, please specify when ordering.
Air consumption
0.2~0.3 m 3/ min, 0.6 Mpa
Voltage & Power
220V, 3.5KW
Touch Screen
7 inch Color displayed Touch Screen
Film Material
Laminated film, such as OPP/CPP, OPP/PE, MST/PE, PET/PE, etc
Film Thickness
50~80μm
Film width
420mm Max.
Finished bag length
50~230 mm
Finished bag width
50~200 mm
Machine frame
Stainless steel 304
Net weight
350kgs
Machine dimension
1300*960*1150mm(LxWxH)
